CSM Reinforcement Rod Anti Corrosion FRP Member

Name: CSM Reinforcement Rod Anti Corrosion FRP Member
Brand: Dingrong
Price: 1 USD

Brand Name : Dingrong

Model Number : Φ0.4-Φ5.0

Certification : ISO9001

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 5000Km/Month

Delivery Time : 30days

Packaging Details : Plywood reel or plastic reel

Spool length : 50.4km/reel, 25.2km/reel or customized

Function : FRP Strength Member

Product Name : FRP Reinforcement

Material : FRP

Packing : Plywood reel or plastic reel

High temperature Bending test (100℃, 24h, 30D) : no cracks, no uneven spots, surface smooth

Number of conductors : ≥ 10,2,4,8,12

Color : Customized

Oem : available

Contact Now

CSM FRP Member FRP Reinforcement Rod Anti Corrosion FRP Strength Member

Optical Fiber Cable Strength Member Features:

1. Specification: 0.4mm-5.0mm (Diameter)

2. Features:

1) High tensile and light weight

2) Electromagnetic interference free

3) Anti-corrosion

4) Environmentally friendly

5) Bullet-proof, ant-proof and anti-tooth proof

3. Application: It is widely used as the central strengthen core for the various fiber optical cables

Specification Of FRP

High tensile strength, high modulus, low heat conductivity, low stretch, low expansion, wide range of temperature settings.
Insensitive to electric shock, suitable for the area with frequent lightning and raining.
Free from chemical corrosion. Compared with metal wire,FRP rod eliminates harmful gas, which can negatively affect cables transmission quality, born chemically by metal and filling gel.
Compared with metal wire, FRP is of high strength, low weight, excellent insulation and immune to electromagnetic interference.
Optical fiber cables with FRP are available to be installed tight close to power wire and power units, perfectly insulated, free from induction current interference. The transmission efficiency can be improved accordingly.
Smooth surface, stable sizes, easy processing and installation contribute to wide range of FRP strength member application.

Property	Value
Appearance	No deffets harmful use such as cracks, uneven spots, and contamination
Tensile strength	≥1100 Mpa
Tensile modulus	≥50 Gpa
Flexural strength	≥1100 Mpa
Flexural modulus	≥50 Gpa
Elongation at break	≤4 %
Diameter tolerance	±2% mm
Minimum bending radius	40*D mm
Density (g/cm3)	2.05-2.15
High temperature bending test (50D,100℃,120h)	No bur, crack and break
Low temperature bending test (50D,-40℃,120h)	No bur, crack and break
